Humidity Sensor, temperature, brightness.

Sensor SHT- X3

New wall sensor for IPX800 , 3 sensors 1.

Compatible Arduino and / or system with analog inputs.

Allows precise control of the relative humidity , temperature , and brightness .

Ipx800 be connected with a shielded cable. ( cat5 or cat6 )

3.3VDC to 5VDC power .


Moisture sensor :

    Measurement of 0 to 90% RH

    Accuracy 3% Resolution 1%
    Resistant to condensation ( used in bathroom for example)
    Honeywell Precision HIH5031 sensor.
    Temperature compensated ( on IPX800 v3) .
    ( 3.3v 0 / ) linear voltage output

TC5050 temperature sensor :

•     From -50 to +50 ° c .
•     Accuracy 2 ° , 0.1 ° resolution .
•     0/3.3v linear output voltage .

Light sensor

•     Measurement of 0 to 100 % in the visible light spectrum . (see doc LS100 )
•     Linear output voltage 0/3.3vdc

Installation:

•     Attach the base of the wall.
•     Unclip the circuit of the  box
•     Connect the cable to the GND, Light , Temp and RH terminals .
•     Clip the circuit on the housing
•     Clip the box on the wall bracket .
•     Connect the cable to the analog inputs of the IPX800 V3
•     Assign each sensor a corresponding entry in the menu IPX800 v3.
